Introduction

Note: Nothing in this standard supercedes applicable laws and regulations.

Note: In the event of conflict between the English and domestic language, the English language shall take

precedence.

1.1 Purpose. This test procedure describes the performance test requirements for elastomeric windshield

washer tubing.

1.2 Applicability. This test procedure is applicable to all elastomeric windshield washer tubing.

1.3 Remarks. None.

2 References

Note: Only the latest approved standards are applicable unless otherwise specified.

2.1 External Standards/Specifications.

ASTM D380 ISO 1 88

2.2 GM Standards/Specifications.

GMW1 6503 GMW1 8267 GMW1 8737

2.3 Additional References. None.

3 Resources

3.1 Facilities.

3.1.1 Calibration. The test facilities and equipment shall be in good working order and shall have a valid

calibration label.

3.1.2 Alternatives. Alternative test facilities and equipment may also be used. However, all measuring variables

as specified in this standard shall be determined correctly with respect to their physical definition.

3.2 Equipment. See Section 4.

3.3 Test Vehicle/Test Piece. See Section 4.

3.3.1 Tests are to be conducted on tubing as supplied.

3.4 Test Time. See Section 4.

3.5 Test Required Information. See Section 4.

3.6 Personnel/Skills. Conform to company and/or laboratory requirements. Technician training records shall be

available upon request.
