GMW3362
$43.00
$19.35
Save 55%
GMW GMW3362 M Point for External Metric Thread, Coarse Pitch Fasteners
standard by General Motors Worldwide , 07/01/2024
Full Description
ENGLISH CURRENT VERSION * CONTAINS COLORPurpose.
This standard specifies the characteristics of M Points for external metric threaded fasteners with coarse pitch; M4, M5, M6, M8, M10, M12, M14, M16, M18, M20 and M22.
Designation.
Type A: Bolts, screws, studs, and double end studs with a standard end point.
Type B: Bolts, screws, and double end studs with an external hex driver end point.
Type C: Bolts, screws, and double end studs with an external six-lobe driver end point.
Type D: Bolts, screws, studs, and double end studs with a long radiused end point to assist locating.
Note: When not explicitly specified, the default shall be Type A.
R00002273
